4G LTE Gateway

Name: WR635G-C1
Brand: Shenzhen Ceres Technology Co., Ltd.

WR635G-C1 is a 4G CAT4 high-performance wireless gateway launched by Shenzhen Ceres Technology Co., LTD. (hereinafter referred to as Ceres). Our 4G LTE smart router supports all Netcom access, including TD-LTE/FDD LTE/WCDMA/TD-SCDMA/GSM/EDGE, using a mainstream chip(ZTE SaneChips) solution with low power consumption. WR635G-C1 4G LTE WLAN router supports three Access scenarios,4G translate to WiFi,4G translate to a wired network, and wired network translate to WiFi. It makes you always keep in touch with the world.

WR635G-C1 4G LTE smart router provides a maximum WiFi access rate of 300Mbps, 1 Ethernet WAN/LAN MIX port, and 1 VoLTE voice port, 2 external antennas for 4G wireless. If you are looking for a suitable 4G LTE WLAN router, welcome to contact us!

 Inquiry  Specification

Specification of 4G LTE Smart Router WR635G-C1
Interface	1xSIM port (2FF) 1x WAN/LAN Ethernet port 1x RJ11 VoLTE port 1x USB2.0 port 1x Reset button
CPU	ZTE ZX297520V3E
Memory /Storage	128MB/64MB
Wireless Access	TD-LTE/FDD/TD-SCDMA/WCDMA/GSM/GPRS/EDGE/EGPRS
Wireless Frequency	FDD:B1/B2/B3/B4/B5/B7/B8/B20/B28A/B28B/B66 TDD:B34/B38/B39/B40/B41 TD-SCDMA:B34/B39 WCDMA:B1/B2/B4/B5/B8 GSM:850/900/1800/1900
Wi-Fi Antennas	2×2.4GHz Internal 3dBi gain
Wireless Antennas	Internal 3dBi gain External 5dBi gain
Wi-Fi Protocol	IEEE 802.11b/g/n
Wi-Fi Speed	2.4G WiFi (Speed 300Mbps)
Ethernet Port	10/100M
LEDs	Power LEDx1 WIFI/WPS LEDx1 Ethernet Status LEDx1 Network Status LEDx1 Wireless Signal LEDx1
Power Supply	DC12V/1A Adapter
Power Consumption	<12W
Operating Temperature	-20～60℃
Storage Temperature	-20～70℃
Dimension/Weight	120 x 150 x 50mm /170g
Certificate	CCC.ROHS
